Specifications Notebook X1590U
CPU Socket - FCBGA1528
CPU & Chipset
Processor Series – 10th Generation (Comet Lake)
• Intel® Comet Lake Core® i3 10110U (2.1GHz base frequency, up to 4.1GHz with Intel® Turbo Boost Technology, 4MB Cache, 2 Cores, 4 Threads)
• Intel® Comet Lake Core® i5 10210U (1.6GHz base frequency, up to 4.2GHz with Intel® Turbo Boost Technology, 6MB Cache, 4 Cores, 8 Threads)
• Intel® Comet Lake Core® i7 10510U (1.8GHz base frequency, up to 4.9GHz with Intel® Turbo Boost Technology, 8MB Cache, 4 Cores, 8 Threads)
Chipset - Onboard SOC
Memory
• 4GB / 8GB / 16GB DDR4 2666MHz (2 x SO DIMM, Upgradability up to 32GB)
• Real Operation frequency depends on processor.
• Dual Channel DDR4 Memory Technology
Graphics
Actual support graphics may vary by CPU.
Total available graphic memory will change according to available memory capacity.
Integrated Graphics Processor
• Intel® UHD Graphics
• Dynamic frequency
• Intel Dynamic Video Memory Technology
• Microsoft DirectX® 12 compatible
Display
• 15.6” LED Backlight HD (1366 x 768) / FHD (1920 x 1080), 16:9 Widescreen panel, Anti - Reflective
Camera
• 1.0MP HD (720P) Video Camera
Storage
• 1x 2.5” – 7.0mm (H) HDD / SSD, SATA Interface
• HDD – 500GB / 1TB (5400rpm)
• SSD – 120GB / 128GB / 240GB / 256GB / 512GB / 1TB
• 1 x M.2 2280 SSD, SATA /PCIe Gen 3x4 Interface - NVMe 128GB / 256GB / 512GB / 1TB (Optional)
Communication
• LAN 10/100/1000 Mbps
• Wireless Module - Intel® Dual Band Wi-Fi 6 AX201, Streams TX/RX 2x2, 802.11ax + Bluetooth 5.2
• LTE M.2 3042 module (Optional)
Keyboard & Pointing Device
• US Keyboard layout with numeric pad & spill-resistant / illuminated keyboard with numeric pad & spill-resistant (optional)
• Pointing Device – Built in touch pad with Microsoft PTP multi gesture & Scrolling function.
Audio
• High-Definition Audio
• Built in Array microphone
• Built in two Speakers.
Operating System
• Linux
• Windows 10 Home 64bit – OEM (Optional)
• Windows 10 Professional 64bit - OEM (Optional)
I/O Ports
• 2 x USB 2.0 Port (Type A)
• 1 x USB 3.2 Gen 1 Port (Type A)
• 1 x USB 3.2 Gen 2 Port (Type C) or 1 x USB 3.2 (Gen 2 Port with power delivery DC in, Type C) (Optional)
• 1 x HDMI Output Port (With HDCP)
• 1 x External VGA Port (Optional)
• 1 x 2 in 1 Audio jack (Headphone / Microphone)
• 1 x Microphone Jack (Optional)
• 1 x RJ-45 LAN Port
• 1 x DC in Jack
Card Reader
• SD Card Reader (MMC / RSMMC / SD / mini SD / SDHC / SDXC)
Optical
• DVD + RW (DL) (Optional)
Power Adapter
• Input 100 – 240V AC, 50-60Hz.
• DC output 19V, 2.1A 40W
Battery
• Removable 4 Cells Smart Lithium-Ion battery pack, 31WH (Battery life - 410 minutes)
• Removable 4 Cells Smart Lithium-Ion battery pack, 41WH (Battery life - 540 minutes)
Security
• Kensington® Type Lock slot
• Intel® PTT for system without Hardware TPM
• TPM 2.0 (Optional)
Optional Requirement
• USB Mouse / Wireless Mouse
• Intel® OptaneTM Technology (For Intel Core Processor Family)
Accessories
• Power Adapter
• Carrying Case / Backpack (Optional)
• Mouse pad, User Manual, Driver DVD
• Recovery media kit with genuine operating system
Dimension & Weight
Dimension W 361 x D 256 x H 24.1mm
Weight – 2.2kg
Design Features - MIL-STD – 810G
Certification - CE, RoHS, FCC, SLS 1580
Manufacture Authorized Warranty – 1 Year / 2 Years / 3 Years / 5 Years (Optional)
Note : Please note that USB 3.0, USB 3.1 Gen1, and USB 3.2 Gen1 are in fact the same specification and feature the same exact performance capabilities. The USB Implementers Forum (USB-IF) recently rebranded USB 3.1 Gen1 to USB 3.2 Gen1. For more information about the change, please visit the USB-IF website at www.usb.org.
