EWIS PRO 3100

EWIS PRO 3100 is specially designed for office users.

EWIS PRO 3100

  • 10th Generation Intel® Core™ Processor
  • Chipset - Intel H410 Series
  • DDR4 Memory upto 64GB
  • Storage Upto 2TB HDD
  • M.2 SSD Storage Upto 1TB - Optional
  • Intel® UHD Graphics
  • Windows 10 Pro
  • Three years comprehensive on-site warranty.



Designed with intense fast performance for Smart Office



Reliable Design: Powerful productivity Quality & latest Technology at the same reasonable price. With various form factors, a desktop that functions seamlessly within your workstation.

Empower every work: Run your software as fast as possible and get real-time results thanks to this memory expandable machine with up to 128GB.



Stay safe & secure: Reduce downtime with certified Hardware. Designed to work with 3200 unbuffered-DIMM memory is the latest upgrade solution that supports Intel/AMD newest platforms for faster data transfer and enhanced power efficiency

Faster access your data: Improve the accessibility of your data with hardware and software with the certified Highspeed PCIe NVMe SSD Drives support Up to 3 times faster than SATA : Read/write speeds of up to 1800/1200MB/s



  • ESD Protection prevents computers from electrostatic discharge damage to enhance
    its durability and lifespan

  • Supports DirectX® 12 to enhance graphical performance

  • Supports HDMI 1.4a Technology ( resolution up to 1920X1200 ) and HDCP function

  • Supports Display Port 1.2 Technology















Form Factor

  • Small Form Factor
  • Mini Tower
  • Micro Tower
  • Tower

CPU Socket

  • FCLGA 1200

CPU & Chipset

Processor Series – 10th Generation (Comet Lake)

  • Intel® Comet Lake Pentium G6400 / G6400T / G6500 / G6500T / G6600
  • Intel® Comet Lake Celeron G5900 / G5920 / G5900T
  • Intel® Comet Lake Core® i3 10100 / 10100F/ 10100T / 10300/ 10300T/10320
  • Intel® Comet Lake Core® i5 10400 / 10400T / 10500 / 10500T / 10600 / 10600T / 10600K / 10600KF
  • Intel® Comet Lake Core® i7 10700 / 10700T / 10700F / i7 10700K / 10700KF

Chipset

  • Intel® H410 Series

Memory

  • 4GB / 8GB / 16GB DDR4 2133/ 2400 / 2666MHz (2 x DIMM, Upgradability up to 64GB)
  • Dual Channel DDR4 Memory Technology
  • Support for Extreme Memory Profile memory modules

Graphics

  • Actual support graphics may vary by CPU
  • Total available graphic memory will change according to available memory capacity

Integrated Graphics Processor

  • Intel® UHD Graphics support 610 / 630
  • Multi-VGA output support: HDMI/DVI-D/RGB
  • Supports HDMI with max. Resolution 4096 x 2160 @ 30 Hz
  • Supports DVI-D with max. Resolution 1920 x 1200 @ 60 Hz
  • Supports RGB with max. Resolution 1920 x 1200 @ 60 Hz Maximum shared memory of 512 MB

Dedicated Graphics

  • GT 210 – 1GB (DDR2 / DDR3 ) (VGA + HDMI ) (Optional)
  • GT 710 1GB / 2GB ( DDR3 / DDR5 ) ( VGA + HDMI + DVI-D ) (Optional)
  • GT 730 4GB DDR3 ( VGA + HDMI + DVI-I ) (Optional)
  • GTX 960 2GB / 4GB DDR5 ( DP + HDMI + DVI-I ) (Optional)
  • GTX 1050 2GB / 4GB DDR5 ( DP + HDMI + DVI-D ) (Optional)
  • Quadro P620 2GB DDR5 (Mini-Display 1.4 x 4) (Optional)
  • GTX 1070 8GB DDR5 ( DP + HDMI + DL -DVI ) (Optional)

Internal Storage

  • 500GB / 1TB / 2TB (3.5” HDD, SATA III , 6Gb/s 7200rpm)
  • SSD 128GB / 256GB / 512GB / 1TB (2.5” SSD) (Optional)
  • M.2 NVMe 128GB / 256GB / 512GB / 1TB (Optional)

Mouse & Keyboard

  • USB Optical Mouse with Scroll wheel
  • USB Standard Keyboard with 104 keys

Audio

  • Realtek ALC887 codec
  • 2/4/5.1/7.1 - Channel
  • High Definition Audio CODEC
  • Internal speaker - (Optional)

Monitor Size & Model - (LED Backlight)

  • 17" - EW170
  • 18.5" - EW185
  • 19" - EW19S
  • 19.5" - EW195
  • 21" - EW21H
  • 21.5" - EW215/ EW215H
  • 23” – EW23T (Touch Monitor)
  • 24" - EW24 / EW24H

Operating System

  • Linux
  • Windows 10 Home 64bit (Optional)
  • Windows 10 Professional 64bit (Optional)

I/O Ports

Small Form Front I/O Ports

  • 2 x USB 2.0 (Type A)
  • 2 x USB 3.2 (Gen 1) (Type A) (Optional)
  • 1 x Microphone-in jack,
  • 1 x Headphone-out jack

Mini / Micro Tower / Tower Form Front I/O Ports

  • 2 x USB 2.0 (Type A)
  • 2 x USB 3.1(Gen 1) (Type A) (Optional)
  • 1 x Card Reader (Optional) / 1 x Type C port (Optional)
  • 1 x Microphone-in jack,
  • 1 x Headphone-out jack

Back I/O Ports

  • 1 x PS/2 Keyboard port (Purple)
  • 1 x PS/2 Mouse port (Green)
  • 1 x DVI-D port
  • 1 x D-Sub port (VGA)
  • 1 x HDMI port
  • 1 x LAN (RJ-45) port
  • 4 x USB 2.0 ports (Type A)
  • 2 x USB 3.2 (Gen 1) (Type A)
  • 3 x Audio Jacks
  • 1 x Serial Port (Optional)

Expansion Slots

  • 1 x PCIe 3.0/ 2.0 x 16
  • 2 x PCIe 3.0 / 2.0 x 1

​

  • Full Height Available in Mini / Micro Tower & ATX Tower Form Factors
  • Half Height Available in SFF Form Factors

Internal I/O Connectors

  • 4 x SATA6Gb/s connectors
  • 1 x USB 3.2 Gen 1 Header
  • 1 x USB 2.0 Header
  • 1 x Serial Header
  • 1 x TPM Header
  • 1 x M.2 Connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x2 SSD Support) (M.2 Connectors Support up to ASPM L1.2 PCIe power management protocols)

Power Supply

  • Input 100 – 240V AC, 50-60Hz
  • 250W / 280W / 300W / 350W / 500W / 750W (Optional)
  • 70% - 90% Efficient Power Supply (Optional)

Driver Bays

  • 2 x 5.25" (External), 2 x 3.5" & 1 x 2.5" (Internal) (Available in Micro Tower & ATX Tower Form Factors)
  • 1 x 5.25" (External), 1 x 3.5" (Internal) (Available in SFF Factors)

Security

Chassis Lock slot (Padlock / Cable lock) / TPM 2.0 (Optional)

Optional Requirement

Special Software /Card Reader / Fire-wire PCIe Card / Dual Monitor Stand (Desk stand Horizontal) / Internal Speaker

Accessories

  • Power cable - 3-pin Square AC plug
  • Mouse pad, User Manual, Driver DVD
  • Recovery media kit with genuine operating system

Dimension


  • Small form factor - L 365 x W 100 x H 292mm
  • Mini Tower - L 365 x W 175 x H 400mm
  • Micro Tower - L 360 x W 180 x H 420mm
  • Tower - L 430 x W 195 x H 500mm

Certification

CE, RoHS, FCC

Warranty

3 Years / 5 Years (Optional)



Note : Please note that USB 3.0, USB 3.1 Gen1, and USB 3.2 Gen1 are in fact the same specification and feature the same exact performance capabilities. The USB Implementers Forum (USB-IF) recently rebranded USB 3.1 Gen1 to USB 3.2 Gen1. For more information about the change, please visit the USB-IF website at www.usb.org.
